Emergency Response Powered by Toyota
Trust the safety and reliability of the Toyota Lite Ace Patient Transport Vehicle and the Hiace Ambulance, where authority meets dependable emergency care.
Calmly Commanding
Embody the gentle dependency of emergency care.
Reliable and Powerful
Toyota’s quality engines mean that you can get the speed and power needed for emergency response without worry of breakdowns.
Know More About Toyota’s Hiace Ambulance and Lite Ace Patient Transport Vehicle
SPECIFICATIONS
Dimension and Weight
| Overall Dimensions (mm) | 4,695 x 1,695 x 2,205 |
| Wheelbase (mm) | 2,570 |
Engine
| Engine Type | 1KD-FTV, 4-Cylinders L Type, 16-Valve DOHC |
| Engine Displacement (cc) | 2,982 |
| Maximum Output (ps/rpm) | 136 / 3,400 |
| Maximum Torque (Nm/Rpm) | 300 / 1,200 ~ 2,400 |
| Fuel Type | Diesel |
| Fuel Capacity (L) | 70 |
Transmission
| Transmission | Manual |
| Power Transmission | 5-Speed Manual (Dash-Mounted) |
Chassis
| Front Brake / Rear Brake | Ventilated Discs / Drums |
| Tires | 195R 15C |
| Wheel (Size) | 6JJ x 15″ |
| Wheel | Steel |
Safety and Security
| Seatbelts Front | 3 Point ELR x 2 Pretensioner Force Limiter |
| Seatbelts Rear | 2pt. NR |
Dimension and Weight
| Overall Dimensions (mm) | 4,045 x 1,665 x 2,120 |
| Seating Capacity | Fr: 2 + Rr: 4 |
Engine
| Engine Type | 2NR-VE, 4-Cylinder In-Line, 16-Valve DOHC with Dual VVT-i |
| Engine Displacement (cc) | 1,496 |
| Maximum Output (ps/rpm) | 98 / 6,000 |
| Maximum Torque (Nm/Rpm) | 134 / 4,400 |
| Fuel Type | Gasoline |
Transmission
| Transmission | 5-Speed Manual |
Interior
| Steering Wheel Material | Urethane |
Exterior
| Headlamp | Halogen |
Chassis
| Front Brake / Rear Brake | Fr: Ventilated Discs Rr: Drum Type |
| Tires | 165R14 |
| Wheels | Steel |
Safety and Security
| Seatbelts Front | Driver + Passenger |
| Toyota Vehicle Security System (TVSS) | Steering Lock |
| SRS Driver Passenger | With |
Conversion Package
| Stretcher | With |
| Fixed Gear Seat w/ Storage | With |
| Foldable Rear Jump Seat | With |
| Fire Extinguisher | With |
| Interior Light | With |
| Assist Grip | With |
| Rear Bumper Protector | With |
| Flooring | With |
| Basic Toplight w/ Siren PA System | With |
Others
| Antenna | Pillar Type |
| Rear Combination Lamps | Halogen |
| Airconditioning | Manual Dial |
| Audio | 2-DIN |
| Speakers | 2 |
| Starting System | Rotary System |
| Steering Type | Electric Power Steering |
